Arrow Shafts

Easton Super Drive Micro

About the product

Easton’s new Super drive Micro 4mm arrow is the latest addition to the popular Super drive family of products. The Super drive Micro is Easton’s highest performing all-carbon arrow designed for all-purpose outdoor tournament use from target to field to 3D. Engineered to provide the lightest grain-per-inch weights possible in a given spine range, the Super drive Micro will maximize your shooting range and minimize your pin gaps, allowing for higher velocities both out of the bow and tighter gaps downrange. The Super drive Micro is available in 11 spines from 325 to 950 providing a choice for the best archers across every division with an extremely tight 0.002 inch straightness spec. Accompanying the Super drive is a full-line of glue-in target points, pin inserts, pin nocks, and direct-fit nocks Components sold separately.

Specifications
For Recurve, Bare Bow & Compound
Multi-layer wrapped 100% carbon-fiber construction
4mm parallel design
Specifically engineered for outdoor competition
Weight Tolerance +/- 1.0 grain
Straightness +/- .002 Inch
Available March 2022

Recommended Parts
4mm ML Point
4mm Pin
Pin Nock Recurve - Small
Pin Nock Compound – Large
4mm Mirco Lite Nock
4mm G Nock

More in this video

Archery Tech Team

Easton Shaft Jazz Purple Arrows

About the product

The Easton Jazz arrow is a budget friendly arrow that is perfect for beginning archers. The Easton Jazz arrow features all the accuracy benefits of XX75 alloy and comes in sizes all the way down to 1214 to outfit any beginning archer. The Easton Jazz arrow can be used for both beginning recurve and compound archers and is best used for indoor type competitions.

Specifications
7075 aerospace alloy.
Hard-anodized-purple finish.
Guaranteed straightness: ± .005”.
Weight tolerance: ± 2%
Strength (psi): 90,000
Components are sold separately.

For non-included but recommended parts/spare parts see the links down below
Easton Points Nibb
Easton Bullet Points For Jazz + Eagle
Easton Inserts RPS 8-32 Aluminum for Shaft Sizes 1716-2613
Easton Uni Bushing Aluminum 4mm Fits G Nock
Easton Nock G Large 98 Groove
Easton Nock G 4mm Small 88 Groove

Archery Tech Team

Easton Shaft FMJ Dangerous Game Arrows

About the product

When it comes to the world’s toughest animals, you need the hardest hitting arrow you can get. The Easton FMJ 5mm Dangerous Game gives deep penetration for the world’s heaviest and thickest skinned animals. Utilizing a high strength, heavy-duty carbon core wrapped in a full beefed up metal jacket. The Easton Dangerous Game has every bit of bone-crushing power you need for hunting anywhere on the planet.

Specifications
High-strength N-FUSED® carbon core with 7075 alloy metal jacket.
Guaranteed straightness: ± .002”.
Easy target pull.
Comes included with Easton X Nock, Brass X HIT conventional thread break-off insert.

For non-included but recommended parts/spare parts see the links down below
Easton Deep Six Steel Field Point
Easton 5mm Deep Six Steel RPS Insert
Easton Broadhead Adapter Ring
Saunders Screw-in Points Combo 12 Pieces

Archery Tech Team

Easton Shaft 5mm Full Metal Jacket Arrows

About the product

The Easton 5mm FMJ (Full Metal Jacket) is fabricated out of a high-strength carbon core with 7075 metal jacket. The Easton 5mm FMJ gives more penetration and adds a kinetic punch for an easier pass through thick hide & bone. The Easton 5mm FMJ comes included with pre-installed Easton X Nocks and Easton HIT 8-32 inserts.

Specifications
High-strength carbon core with 7075 metal jacket.
Easy target pull.
Straigtness: ± .002”.
Comes included with HIT 8-32 inserts and pre-installed Easton X Nocks.
Other parts are sold separately.

For non-included but recommended parts/spare parts see the links down below
Easton Deep Six Steel Field Point
Easton 5mm Steel 8-32 Half-out
Easton 5mm Deep Six Steel RPS Insert
Easton 5mm Brass HIT Break-off 8-32 Insert
Easton 5mm Aluminum 8-32 Half-out
Easton Broadhead Adapter Ring
Saunders Screw-in Points Combo 12 Pieces

More in this video

Archery Tech Team

Easton Target Shaft X10 Arrows

About the Product

The ultimate recurve competition shaft. The Easton X10 has won more World and Olympic titles than any other arrow- or any other archery product of any kind- since its competition debut at the 1996 Olympic Games in Atlanta, USA. Since making that gold-medal-winning debut, it has gone on to be used to win every single Olympic Medal since the Atlanta Games. High-modulus carbon fiber on a precision, thin-wall aluminum core creates an unmatched synergy of precision and durability. With components engineered to match the performance of this ultimate target shaft, every size X10 features a custom barreled design, providing the ultimate in clearance, finger release forgiveness, and the correct frequency match for modern recurve bows. X10. Nothing else comes close.

Made with pride by Easton in the USA.

Specs
High-strength carbon fiber bonded to a 7075 precision alloy core
Polished 9-micron carbon finish
Straightness: ± .0015”
Weight tolerance: ± 0.5 grains per packaged dozen
Weight coded for precision matching between dozens
Components—sold separately
Barreled design
Used to win every Olympic title since 1996

More to see in this video

1. Due to the barrel design of the X10, the weight is an average grains-per-inch of a 29” shaft. Shaft weight is slightly heavier in the larger diameter center and lighter toward the tapered ends. One inch of shaft cut from the point end typically weighs 6-7 grains.
2. Nominal O.D. at mid-point of shaft. Ends are smaller. Point end is larger diameter than nock end.
3. Recommended that no more than these lengths be cut from the point end of the shaft.

For non-included but recommended parts/spare parts see the links down below

X10 point tungsten
X10 point steel
X10 outnock
pin nock
G pin nock (compound)

Archery Tech Team

Easton Target Shaft ACE

About the product

A/C/E -Aluminium Carbon Extreme- is the arrow which started a revolution that continues to this day. Light, strong and proven across the globe. Popular recurve or compound field shaft.

SPECIFICATIONS
High-strength carbon fiber bonded to a 7075 alloy core
Polished black carbon finish
Straightness ± 0.0015”
Weight tolerance ± 0.50 grains
Components—sold separately
Barreled design
Made in USA

GPI - Due to the Barrel design of ACE , the grain weight per inch shown is an average weight per inch GPI of a 29 inch shaft. The shaft weight is slightly heavier in the larger diameter and lighter towards the taper ends. One inch of shaft cut from the point end typically weighs 5-6 Grain.
O.D. outher diameter, Nominal O.D. at mid front of the shaft. Ends are smaller.
Trim Inches - Recommended that no more than these lenghts be cut from the front end of the shaft.

Archery Tech Team

Easton Target Shaft X10 Protour

About the product

Since its introduction, the compound-specific X10 Protour has won more titles and set more records for compound archers than all other choices combined. Specifically engineered for compound target competition, Protour features a front taper allowing for every size to use Easton X10 point components- the same components that have been used to win every Olympic medal since 1996. The precisely engineered mass to spine ratio of each Procomp size ensures the best ballistic performance at longer compound competition distances, and gives archers an undeniable edge in unpredictable windy weather. With unmatched precision and legendary durability in even the most abusive target materials on the world circuit, Procomp is at the absolute performance pinnacle for compound target precision. Every Procomp arrow is proudly Made in USA by Easton.

Specifications
Lightweight, high-modulus carbon fiber bonded to a precision 7075 alloy core
Polished black carbon finish
Straightness ± .0015 Inch
Weight tolerance ± 0.5 grains
Components—sold separately
Tapered design
Made in USA

More info in this video

GPI - Due to the taper design of the X10 Pro Tour, the grain weight per inch shown is an average weight per inch GPI of a 29 inch shaft. The shaft weight is slightly heavier toward the lager diameter nock end and lighter toward the tapered frond end. One Inch of the shaft cut from the point end typically weighs 6-7 Grain.
O.D. outher diameter, Nominal O.D. at mid front of the shaft. Frond end is smaller.
Trim Inches - Recommended that no more than these lenghts be cut from the front end of the shaft.

For non-included but recommended parts/spare parts see the links down below

X10 tungsten point
X10 steel point
Pin nock
G pin nock (compound)

Archery Tech Team

Easton Shaft ProComp 2019 Arrows

About the product

Highest quality and high performance normally come with a hefty price tag. Well not any more. Easton’s new A/C Procomp arrow is now available for compound target and field competition. The light-weight, high speed, parallel design Procomp is designed for archers looking to boost their scores at competitive and club-level compound events. The Procomp was proven at high level tournament circuits in the 2018 outdoor season by World Champions: Steven Anderson and Braden Gellenthien. Taking five World Archery podiums and another at the first event of the 2019 World Cup season. The 4mm Procomp features Easton’s unmatched spine accuracy and precision weight accuracy using the exclusive, high modulus carbon and super strong alloy core construction. The 4mm Procomp is an easy to tune shaft using accurate aluminum-carbon construction with reduced wind drifting and offered at an attractive price.
The new Procomp arrow is compatible with most 4mm Easton components including direct fit G nocks and Deep Six nocks (recommended for high energy compound cam systems). See the included arrow chart for details on compatible point and pin nock systems. All Procomp shafts come in a factory sealed dozen pack (12 arrow shafts) with a ±1,0 grain weight tolerance (0,065 g).

Specifications
High strength carbon fiber bonded to a 7075 alloy core
Straightness: ±0,0015”
Weight tolerence: ±1,0 grain (0,065 g)
Parallel design

For non-included but recommended parts/spare parts see the links down below

4mm ml stainless steel break off point
4mm pin
4mm g nock
pin nock
G pin nock
4mm microlite nock

More in this video

Archery Tech Team

Easton Shaft XX75 Black Gamegetter

About the product

A true bow hunting legend. More game has fallen to Easton XX75s than any other hunting arrow ever made. Get the nostalgia of this bow hunting favorite.

Specs
Pre-installed Super Nocks (installed)
RPS inserts not included
Sizes 300-2317, 340-2315, 400-2117 and 500-2016
7075-T9 alloy
Straightness ± 0.003 Inch

Please note Shafts only

Archery Tech Team

Easton Shaft XX75 Camo Hunter

About the product

A Made-in-the-USA American classic. Deliver your fieldpoint with precision-build XX75 Accuracy.

Specs
Pre-installed UNI bushings without nocks
RPS inserts not included
7075-T9 alloy
Tensile strength psi 96,000
Guaranteed straightness ± 0.002 Inch

Archery Tech Team

Easton Shaft XX75 Kyudo

About the product

Kyudo shaft from Easton.

For use in traditional, Japanese Kyudo archery.
Stock length of 1.10 meter - 43.30 Inch.
Aluminum shaft with a partial swage and without bushings.
Technical specifications:

Spine 1913 fits 9/32 nock
Spine 2014/2015 fits 5/16 nock

Archery Tech Team

Easton Shaft XX75 Platinum Plus Arrows

About the product

Platinum Plus is a premium, intermediate priced shaft for all levels of recreational and competitive archery.

Specs

7075-T9 aerospace alloy
Hard-anodized finish
Guaranteed straightness ± .002 Inch
Weight tolerance ± 1%
Strength psi 96,000
G-UNI bushing sizes 1416 to 1916 or Super UNI Bushing sizes 2013 to 2315
Components—sold separately
Sizes: 1416, 1516, 1616, 1713, 1716, 1813, 1816, 1913, 1916, 2013, 2016, 2114, 2213, 2315

Archery Tech Team

Easton Shaft XX75 Tribute Arrows

About the product

The Easton XX75 Tribute arrows are a durable, accurate and economical option for beginner or shorter draw lighter poundage archers. The Easton Tribute is the stepping stone to high performance for beginner or shorter draw lighter poundage archers. The Easton Tribute arrows have a hard-anodized black finish and come with a guaranteed straightness of ± .005” across all the available sizes.

Specifications
7075 aerospace alloy.
Hard-anodized black finish.
Guaranteed straightness: ± .005”.
Weight tolerance: ± 2%.
Strength (psi): 90,000.
Precision-ground nock swage.
Components are sold separately.
The 1214 size arrow uses the direct-fit G Nock

For non-included but recommended parts/spare parts see the links down below
Easton Points Nibb
Easton Nock G Large 98 Groove
Easton Nock G 4mm Small 88 Groove
Easton Inserts RPS 8-32 Aluminum for Shaft Sizes 1716-2613
Bohning Nocks 5/16 Inch Classic

Archery Tech Team

Easton Shaft Genesis Teal 1820 Arrows

About the product

The Easton Genesis arrow is the only approved arrow by NASP Tournament Competition. The Easton Genesis is based on Easton’s XX75 technology. The Genesis arrow is accurate, durable and an economical choice. The Genesis comes installed with Easton UNI bushings.

Specifications
7075 aerospace alloy.
Hard-anodized finish.
Straightness: ± .005”.
Weight tolerance: ± 2.5%.
Strength (psi): 90,000
UNI bushing pre-installed.
The ONLY arrow approved for all NASP tournaments and events.
MADE IN USA.

For non-included but recommended parts/spare parts see the links down below
Easton Points One Piece 1820 Genesis Nickel
Easton Nocks N Genesis

Archery Tech Team

About the Product

NEW Easton RX7- The Ultimate Indoor Recurve Arrow Shaft

Easton’s exclusive tapered technology allows a bigger line-catcher arrow at lower bow and/or point weight
New for the 2020 indoor season, Easton announces the most accurate, technically advanced indoor arrow shaft ever devised for recurve finger shooters- the all-new RX-7 series.
Available in three spine values- 525, 475, and 420- in a 21, 22, and World Archery Maximum 23 diameter.
Easton’s new RX-7 series 7178 aluminum arrow shafts incorporate a precision rear taper – effectively letting recurve shooters shoot a bigger arrow at a lower bow weight, and also with less point weight, while maintaining maximum shaft diameter for higher scoring potential.
Proven in the 2018-19 competition season by some of the top archers in the world, including Team USA’s Brady Ellison and Jack Williams, the RX-7 is based on the same proven design principle as Easton’s X10 and A/C/E shafts, with the precision flexible, forgiving rear taper.
Williams said: “The rear tapered design of the RX-7 creates the most forgiving aluminum arrow for a recurve archer. It allows archers to use a lighter point weight to achieve the proper tune, creating a faster release and better arrow flight.”
This design element drops the dynamic spine of the arrow shaft by up to one full size, which allows the use of a larger diameter and lighter point.
Until now, many shooters seeking maximum diameter arrow shafts often needed to compromise the bow tune, and potentially compromise shooting technique forgiveness, by using super-heavy points, leading to greater error potential with slight natural release inconsistencies.
By using a normal weight point, and a precision engineered, more flexible rear taper with a weight-forward design, RX-7 series shafts provide the ultimate in finger release forgiveness. RX-7 uses full-strength 7178-T9 alloy that easily copes with tough European target materials.
For example, the RX-7-23 has a spine of 0.420, compared to a spine of 0.342 for the equivalent Easton X23 2315 shaft. As an example, this allows the RX-7-23 420 to be tuned with an Easton 2315 100 or 125 grain bullet point, at a normal shaft length. Compare this to the X23 2315, which is often tuned by recurve shooters with a heavy, 200 or 300 grain aftermarket point, at a longer than normal shaft length. The 21 and 22 sizes accept both Easton one piece bullet points or NIBB points for the 2114 or 2214 sizes, respectively.
RX-7 shafts are supplied with Easton Super-UNI bushings, which accept available Easton Super Nocks, 3D-Super Nocks, and the popular size 19 Beiter nock.
The updated tuning chart for the RX-7 is available online at www.eastonarchery.com
RX-7 shafts are available from your authorized Easton dealer now, and are 100% Made in the USA.
